Dahua NVR4232-4KS3 32 Channel 1U 2 HDD Network Video Recorder NVR
Key FeaturesModel - NVR4232-4KS3Resolution : 8MP/5MP/4MP/3MP/1080P/720P/D1/CIFNumber of Input Channel - 04 ChannelMax. 160/128/60 Mbps incoming/recording/outgoing bandwidthAI by Re...
Dahua NVR4232-4KS3 32 Channel 1U 2 HDD Network Video Recorder NVR
Quick Overview
- Model - NVR4232-4KS3
- Resolution : 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF
- Number of Input Channel - 04 Channel
- Max. 160/128/60 Mbps incoming/recording/outgoing bandwidth
- AI by Recorder supports 2-channel SMD Plus
The Dahua NVR4232-4KS3 32 Channel 1U 2 HDD Network Video Recorder NVR is a 32-channel network video recorder of high quality made to provide strong performance and extensive surveillance management. It is perfect for companies, offices, warehouses, educational institutions, and commercial facilities that need comprehensive security coverage because it supports up to 32 IP camera inputs. This NVR's 1U rack-mountable architecture makes it small and effective, and it can accommodate up to two HDDs for more video storage.
The NVR4232-4KS3 guarantees that every detail is recorded with remarkable clarity during recording and playback, thanks to its 4K ultra-high definition resolution. It makes use of cutting-edge H.265 and H.264 video compression technologies, which preserve excellent image quality while using less storage and bandwidth. It has several USB ports for convenient video export and backup, and HDMI and VGA outputs for a variety of high-definition display options.
For both IT administrators and non-technical users, the NVR's intuitive interface simplifies setup and day-to-day management. Users may access playback, monitor live feeds, and remotely manage their system from PCs, tablets, or smartphones using Dahua's mobile app, guaranteeing constant monitoring even when they're not there.
The NVR4232-4KS3, which is designed for scalability and stability, facilitates sophisticated video analytics, dependable data transfer, and smooth interaction with Dahua's extensive selection of IP cameras. It is ideal for long-term recording needs in bigger surveillance projects because of its dual hard disk design, which provides increased storage flexibility.
Overall, the Dahua NVR4232-4KS3 32 Channel 1U 2 HDD Network Video Recorder NVR combines powerful performance, large storage capacity, and advanced features in a compact form factor, making it a perfect solution for organizations that demand reliable and professional video surveillance management.
| General Specification | |
|---|---|
| Brand | Dahua |
| Model | NVR4232-4KS3 |
| System | |
| Main Processor | Industrial-grade embedded processor |
| Operating System | Embedded Linux |
| Display | |
| Interface | 1 × VGA Output; 1 × HDMI Output; Supports Simultaneous Video Sources Output for VGA and HDMI |
| Resolution | VGA: 1920 × 1080; 1280 × 1024; 1280 × 720 HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 |
| Decoding Capacity | AI Disabled: 2-Channel 32 MP@25 fps; 2-Channel 24 MP@25 fps; 4-Channel 16 MP@30 fps; 5-Channel 12 MP@30 fps; 8-Channel 8 MP@30 fps; 10-Channel 6 MP@30 fps; 12-Channel 5 MP@30 fps; 16-Channel 4 MP@30 fps AI Enabled: 1-Channel 32 MP@25 fps; 1-Channel 24 MP@25 fps; 2-Channel 16 MP@30 fps; 4-Channel 12 MP@30 fps; 6-Channel 8 MP@30 fps; 8-Channel 6 MP@30 fps; 8-Channel 5 MP@30 fps; 12-Channel 4 MP@30 fps |
| Multi-Screen Display | Main Screen: 1/4/8/9/16; Sub Screen: 1/4/8/9/16 |
| Recording | |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Recording Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 720p; 960p; D1; CIF; QCIF |
| Record Mode | General; Motion Detection; Intelligent; Alarm; POS |
| Video Detection & Alarm | |
| Alarm Input | 4 Channels |
| Playback & Backup | |
| Playback Function | Instant Playback; General Playback; Event Playback; Tag Playback; Smart Playback (Face and Motion Detection) |
| Backup Mode | USB Device and Network |
| Network | |
| Ethernet Port | 1 × RJ-45, 10/100 Mbps Self-Adaptive Ethernet Port |
| Network Function | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search; P2P; Auto Register |
| Storage | |
| Internal HDD | 2 × SATA Ports; Each Disk Up to 20 TB; Limit Varies Depending on Environment Temperature |
| Auxiliary Interface | |
| USB | 2 × USB 2.0 (1 Front; 1 Rear) |
| Power | |
| Power Supply | 12 VDC, 4 A |
| Power Consumption | Total Output of NVR ≤ 10 W (Without HDD) |
| Component Environment | |
| Operational Conditions | –10 °C to +55 °C (14 °F to +131 °F) |
| Storage Conditions | –20 °C to +60 °C (–4 °F to +140 °F) |
| Construction | |
| Dimensions | 375.0 × 284.4 × 56.0 mm (W × D × H) |
| Net Weight | 1.57 kg |
| Gross Weight | 2.73 kg |
| Warranty | |
| Manufacturing Warranty | 1 Year |
