Dahua NVR1108HS-8P-S3/H 8 Channel Network Video Recorder NVR
Key FeaturesModel - NVR1108HS-8P-S3/HVideo - Smart H.265+/Smart H.264+/H.265/H.264Number of Input Channel - 08 Channelup to 8 TB for a single HDDMax 80Mbps incoming bandwidth
Dahua NVR1108HS-8P-S3/H 8 Channel Network Video Recorder NVR
Quick Overview
- Model - NVR1108HS-8P-S3/H
- Video - Smart H.265+/Smart H.264+/H.265/H.264
- Number of Input Channel - 08 Channel
- up to 8 TB for a single HDD
- Max 80Mbps incoming bandwidth
The Dahua NVR1108HS-8P-S3/H 8 Channel Network Video Recorder NVR is a strong 8-channel network video recorder that is a great option for medium-sized security systems because it has built-in Power over Ethernet (PoE) capability. This NVR's eight separate PoE connectors make installation easier by allowing IP cameras to receive power and data from a single cable, which lowers setup complexity and costs. It is ideal for residences, workplaces, and companies in need of a dependable and user-friendly monitoring system.
The NVR ensures clear and detailed video coverage by supporting up to eight high-definition IP cameras and providing seamless recording and playback. It uses cutting-edge H.265 and H.264 video compression technologies, which drastically cut down on storage needs and bandwidth consumption without sacrificing video quality. USB connections enable easy backup of recorded video, and HDMI and VGA outputs provide a variety of video display possibilities.
With its straightforward interface, the NVR1108HS-8P-S3/H is made to be easy to use and quick to configure and operate on a daily basis. Users may remotely access live feeds and replay from their PCs, tablets, or smartphones using Dahua's mobile application, guaranteeing continuous monitoring even when they're not there.
Overall, the Dahua NVR1108HS-8P-S3/H 8 Channel Network Video Recorder NVR, which is small in size but packed with capabilities, guarantees consistent performance, effective storage management, and smooth interaction with Dahua's extensive selection of IP cameras. The Dahua NVR1108HS-8P-S3/H is a reliable option for anyone looking for continuous and secure monitoring since it strikes the ideal balance between affordability, performance, and ease of use.
| General Specification | |
|---|---|
| Brand | Dahua |
| Model | NVR1108HS-8P-S3/H 8 |
| Type | NVR |
| Video Info | |
| Number of Input Channel | 08 Channel |
| Video Compression / Format | Smart H.265+; Smart H.264+; H.265; H.264 |
| Video Output (VGA) | 1 × VGA, 1920 × 1080 |
| Video Output (HDMI) | 1 × HDMI, 1920 × 1080 |
| Max. Video Recording Resolution | 1920 × 1080 |
| Audio Info | |
| Audio Input Channel (RCA) | 1 × RCA |
| Audio Compression | PCM; G711A; G711U; G726; AAC |
| Audio Output Channel | 1 × RCA |
| Recording & Decoding | |
| Live View / Playback Resolution | 8 MP; 5 MP; 4 MP; 3 MP; 1080P; 720P; D1; CIF |
| Decoding Capability | 1-Channel 8 MP@30 FPS; 1-Channel 5 MP@30 FPS; 2-Channel 4 MP@30 FPS; 2-Channel 3 MP@30 FPS; 4-Channel 1080P@30 FPS; 8-Channel 720P@30 FPS |
| Synchronous Playback | 08 Channel |
| Network | |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; P2P |
| Wi-Fi | No |
| Network Interface (RJ45) | 1 × RJ-45 Port (10/100 Mbps) |
| PoE Interface | No |
| Auxiliary Interface | |
| Number of HDD Interface (SATA) | 1 SATA |
| Max. HDD Support (GB, TB) | Up to 8 TB |
| Max. Storage Support | 8 TB |
| USB Port | 1 × USB 2.0 (Front); 1 × USB 2.0 (Rear) |
| Technical Info | |
| Main Processor | Embedded Processor |
| Display Split | 1/4/8/9 |
| Incoming Bandwidth | 80 Mbps (Access) |
| Outgoing Bandwidth | 80 Mbps (Storage); 60 Mbps (Forwarding) |
| Backup Storage | USB Device |
| Compatibility | |
| Operating System | Embedded Linux |
| Power Info | |
| Power Supply | DC 12 V, 1.5 A |
| Approx. Power Consumption | <10 W (Without HDD) |
| Max. Power | 10 W |
| Physical Description | |
| Color | Black |
| Dimensions | 260 × 225 × 47.6 mm (W × L × H) |
| Weight | 0.81 kg |
| Warranty | |
| Warranty | 2 Year (Without Adapter) |
