Hikvision DS-7632NXI-K2 AcuSense 32-Channel 4K NVR
Key FeaturesModel: DS-7632NXI-K2Channels: 32 ChannelType: 4K NVRCompression: H.265+/H.265/H.264+/H.264Output: 4K HDMI
Hikvision DS-7632NXI-K2 AcuSense 32-Channel 4K NVR
Quick Overview
- Model: DS-7632NXI-K2
- Channels: 32 Channel
- Type: 4K NVR
- Compression: H.265+/H.265/H.264+/H.264
- Output: 4K HDMI
The Hikvision DS-7632NXI-K2 32-Channel 4K NVR is a high-performance network video recorder designed for large-scale security surveillance systems where reliability, storage efficiency, and intelligent video management are top priorities. This advanced NVR supports up to 32 IP camera inputs, making it suitable for commercial facilities, office complexes, industrial sites, and enterprise-level security networks. With support for ultra-high-definition 4K video recording and playback, it ensures that every detail is captured with clarity, which is crucial for accurate monitoring, evidence collection, and incident review.
Engineered with Hikvision’s cutting-edge technology, the DS-7632NXI-K2 comes equipped with advanced video compression standards that significantly reduce storage requirements without compromising video quality. It supports multiple video formats and offers smooth video streaming even in environments with limited bandwidth. Its powerful decoding capability allows simultaneous playback of multiple high-resolution channels, ensuring security personnel can monitor live feeds while reviewing recordings with ease.
This NVR features a robust storage system with multiple SATA interfaces, enabling the installation of large-capacity hard drives for extended recording periods. The intelligent search and playback functions make it simple to retrieve specific video footage based on events, motion detection, or time filters. Additionally, it supports remote access via mobile apps and web clients, providing users with real-time monitoring and playback capabilities from anywhere, which enhances flexibility and operational efficiency.
The DS-7632NXI-K2 also incorporates advanced security features such as intrusion detection, facial recognition, line crossing detection, and other deep-learning-based analytics to provide proactive surveillance. These AI-driven functions help reduce false alarms and ensure that critical incidents are detected and flagged instantly. With a user-friendly interface, intuitive configuration, and compatibility with various third-party devices, this NVR offers a seamless integration experience for both small and large security networks.
Built with durability in mind, the Hikvision DS-7632NXI-K2 ensures stable performance 24/7, backed by efficient heat dissipation and reliable hardware components. Whether used for corporate offices, retail outlets, warehouses, or public institutions, this 32-channel 4K NVR delivers a comprehensive and future-proof security solution that meets the growing demands of modern surveillance.
| General Specification | |
|---|---|
| Brand | Hikvision |
| Model | DS-7632NXI-K2 |
| Type | NVR |
| Video Info | |
| Number of Input Channel | 32 Channel |
| Video Compression / Format | H.265 / H.265+ / H.264+ / H.264 |
| Video Output (VGA) | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video Output (HDMI) | 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| Video Recording Resolution | 1920 × 1080 |
| Max. Video Recording Resolution | 3840 × 2160 |
| IP Video Input | 32-ch |
| Audio Info | |
| Audio Input Channel (RCA) | 1 Channel RCA |
| Audio Compression | G.711ulaw / G.711alaw / G.722 / G.726 / AAC |
| Audio Output Channel | 1 Channel RCA |
| Two-Way Audio | 1-ch, RCA (Linear, 1KΩ) |
| Recording & Decoding | |
| Stream Type | Video, Video & Audio |
| Dual Stream Support | No |
| Live View / Playback Resolution | 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Decoding Capability | AI On: 1-ch @ 12 MP (30 fps) / 2-ch @ 8 MP (30 fps) / 4-ch @ 4 MP (30 fps) / 8-ch @ 1080P (30 fps); AI Off: 2-ch @ 12 MP (30 fps) / 3-ch @ 8 MP (30 fps) / 6-ch @ 4 MP (30 fps) / 12-ch @ 1080P (30 fps) |
| Synchronous Playback | 16-ch |
| Network | |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Wi-Fi | No |
| Network Interface (RJ45) | 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet interface |
| PoE Interface | No |
| Remote Connections | 128 |
| Auxiliary Interface | |
| Number of HDD Interface (SATA) | 2 SATA |
| Max. HDD Support | Up to 10TB capacity for each HDD |
| Max. Storage Support | 20TB |
| USB Port | Front Panel: 1 × USB 2.0; Rear Panel: 1 × USB 2.0 |
| Technical Info | |
| Incoming Bandwidth | 256 Mbps |
| Outgoing Bandwidth | 160 Mbps |
| Video Detection | Motion Detection 2.0 |
| Compatibility | |
| Smart Phone Supported | Yes |
| AI Features | |
| AI Technology | Hikvision AcuSense technology |
| AI by Device | Facial recognition, perimeter protection, motion detection 2.0 |
| AI by Camera | Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, VCA |
| Facial Detection & Analytics | Face picture comparison, human face capture, face picture search |
| Face Picture Library | Up to 16 face picture libraries, with up to 20,000 face pictures in total; each picture 4 MB, total capacity 1 GB |
| Facial Detection & Analytics Performance | 1-ch, 8 MP |
| Face Picture Comparison | 4-ch |
| Power Info | |
| Power Supply | 12 VDC, 3.3 A |
| Approx. Power Consumption | < 15 W (without HDD) |
| Physical Description | |
| Color | Black |
| Dimensions | 385 × 315 × 52 mm |
| Weight | < 1 kg |
| Warranty | |
| Warranty | 2 Years (Without Adapter) |
